Description
What Bolt Tension Capacity Calculation calculates
Bolt Tension Capacity Calculation is a professional structural and civil engineering calculation tool that takes 9 engineering inputs and produces 6 verified results. The calculation follows AISC 360. Every formula is traceable to the governing code clause, and every result is checkable against the worked example.
Input parameters
You provide these values from your project data:
| Parameter | Symbol | Unit | Example value |
|---|---|---|---|
| Bolt Nominal Diameter | input_D9 | mm | 20 |
| Thread Pitch | input_D10 | mm | 2.5 |
| Bolt Grade | input_D11 | — | 8.8 |
| Yield Strength | input_D12 | MPa | 640 |
| Ultimate Tensile Strength | input_D13 | MPa | 800 |
| Number of Bolts | input_D16 | — | 4 |
| Total Applied Tension | input_D17 | kN | 100 |
| Prying Action Factor | input_D18 | — | 1.1 |
| Partial Safety Factor | input_D28 | — | 1.25 |
Calculation results
The spreadsheet produces these verified outputs from your inputs:
- Tdb2
- Tdb
- Ft
- Ur Aisc
- Ur Is
- A38
Governing standards and codes
This calculation complies with:
- AISC 360
Each formula references the applicable code clause so your reviewer can trace every calculation step back to the standard.
What you receive
- Excel calculation file (.xlsx) — fully unlocked formulas, 10 calculation steps, clear input/output layout
- Worked example — realistic engineering values with expected outputs for independent verification
- Code references — every formula cross-referenced to AISC 360
- Free online calculator — try your values instantly using the calculator above before purchasing
- Engineering support — email info@3d-labs.com for questions about inputs, methodology, or results
Try before you buy
Use the free calculator above to check your values with a single set of inputs. For unlimited calculations, editable formulas, and a professional calculation report, purchase the full spreadsheet at ₹999. One payment, lifetime access, no subscription.
