AISC Bolting Design Calculations β Steel Connection Excel Workbook β method, governing standards and output schedule
The AISC Bolting Design Calculations β Steel Connection Excel Workbook sizes a bolted joint for the applied tension, shear and combined loading, establishing the required preload and the assembly torque, and reporting the margin against bolt yield, joint separation and slip. It is applied during detailed design, during design verification by a second engineer, and again during in-service assessment when the operating basis changes. Because every intermediate quantity is reported rather than only the final answer, the calculation can be checked line by line against the governing standard without re-deriving it.
This 3D-LABS workbook is built to AISC 360. Every formula is left visible so each figure can be traced to the clause it comes from.
Method of calculation
Required preload is set as a proportion of the bolt proof load, and the torque to achieve it follows from the nut factor or from the long-form relation that separates thread friction, bearing friction and the pitch term. Joint stiffness and bolt stiffness determine the load factor that splits external load between bolt and joint, which governs both the separation check and the alternating stress used in the fatigue assessment. Shear is checked for bolt shear, bearing on the connected plies and, for slip-critical joints, for slip resistance.
Governing standards and references
- AISC 360 β ANSI/AISC 360 Specification for Structural Steel Buildings
- VDI 2230 β VDI 2230 Systematic calculation of highly stressed bolted joints
- ASME PCC-1 β ASME PCC-1 for assembly torque of pressure boundary joints
Each formula cites the clause it comes from on the same row as the result it produces, so a reviewer can check the sheet line by line against the standard.
Acceptance criteria
For the calculation to be reported as acceptable, bolt stress under preload plus external load must remain below the permitted proportion of yield, the joint must not separate at the design load, and shear, bearing and slip checks must each be satisfied.
Who uses this calculation
This calculation is used by mechanical and structural engineers designing bolted connections, maintenance engineers issuing torque values, and reviewers auditing joint integrity.
What you receive
- Excel calculation file (.xlsx) β fully unlocked formulas and a clear input/output layout
- Worked example β realistic engineering values with expected outputs so you can verify the sheet against a known case
- Code references β every formula cross-referenced to AISC 360
- Email support β write to info@3d-labs.com with questions about inputs, methodology or results
Delivery and licence
Instant download after payment at βΉ500. One payment, lifetime access, no subscription. The workbook is a design aid β results must be verified by a qualified engineer before use.
