Which codes do you follow for bolted tank design?

AWWA D103 for water storage tanks. AS 2304 for Australian projects. API standards for petroleum service. EN 14015 for European projects.

What materials do you specify?

Zincalume (55% Al-Zn coated steel), glass-fused-to-steel (GLS), epoxy-coated steel, and stainless steel. Coating selection depends on service, temperature, and design life.

What sizes can you design?

Bolted tanks and silos from 4,647 mm to 12,000 mm standard diameter. Larger custom sizes on request. Cone inclinations 45°, 55°, and 60° for silos.

What applications do you cover?

Water sector (potable, waste water, fire protection, sludge), dry bulk (gravel, hardcore, grain, cement), and chemical storage.

What is your typical delivery time?

Basic tank design and GA: 10-14 working days. Full deliverable including panel layout, bolt schedule, and foundation: 20-25 working days.

Professional Bolted Storage Tank Design Services

Bolted Storage Tanks and Silos Design Services

Welcome to 3D-LABS, your premier destination for Bolted Storage Tanks and Silos Design services. Our team of skilled professionals has been delivering top-quality engineering solutions since 2003, utilizing the latest technologies to ensure effective execution. We understand the critical role efficient storage plays in handling bulk materials, whether dry goods, liquids, or granular substances. That’s why our customized designs prioritize reliability, durability, and optimal capacity, tailored to your specific needs.

At 3D-LABS, we employ advanced engineering principles and cutting-edge simulation tools to ensure structural integrity and longevity. Our use of premium-grade steel panels, assembled with high-strength bolts and gaskets, guarantees a secure and leak-proof structure. We prioritize smooth material flow, minimizing degradation and enhancing operational efficiency. We offer flexibility and customization to accommodate unique project requirements, whether it’s multiple compartments, specialized discharge mechanisms, or additional safety features.

Our commitment to customer satisfaction ensures that your storage solution meets the highest standards of reliability and durability. With 3D-LABS, you can trust in our expertise to deliver superior bolted storage tank and silo designs that support your bulk storage objectives. Contact us today to discuss your needs and experience the benefits of working with a trusted industry leader. specialized in AWWA,AS2304,API,EN etc. give in points

A bolted steel storage tank is composed of rolled steel tank panels that are connected together via bolted
connections to form a vertical cylinder used for the storage of liquid and dry bulk materials.

Applications of Bolted Tanks Water Sector: Storage of Drinking or Potable Water, Rural Water Districts, Subdivision/Private Water Systems, Water Storage at Municipality, Fire Protection Systems, Waste Water, Finish Water, Process Water, Disinfection, Filtration and Sludge Storage

Bolted silos are mainly used to store large quantities of various bulk materials, in particular gravel, hardcore, chippings, and non-metallic minerals.

The silos are manufactured with standard diameters of 4,647 mm – 12,000 mm. Cone inclinations of 45°, 55°, and 60° are available.

completed projects

Zincalume Bolted Storage Tank ForLars Enviro Pvt Ltd, Jaipur
Waste Water Storage Tank ForMorganite Crucible India Ltd,Maharastra
Raw Water Storage Tank For ZydusCadila Research CentreAhmedabad
Gls Tank For Lars Enviro Pvt Ltd,Jaipur
Raw Cum Fire Water Storage TankFor Aker Power Gas Pvt.Ltd, India.
Fire Water Storage Tank For TheRed Sea Developemnt Company,Saudi Arabia.
Fire Water Storage Tank In KuwaitLocation For R P Ltd.India.
Potable Water Storage Tank ForM/S Qatar Kentz W.L.L.
Zincalume Water Storage Tank For L&T, India.
Zincalume Water Storage Tank For Ncc,Hyderabad, India.
Irrigation Water Storage Tank In Saudi Location For R P Ltd. India.
Potable Water Storage Tank In Africe Location For R P Ltd. India.
Maize Stored Flat Bottom Silo For RP Ltd.
Soyabean Stored Flat Bottom SiloFor R P Ltd.
Rice Stored Flat Bottom Silo For R P Ltd..
Animal Pellet Stored Hopper Bottom Silo For R P Ltd

silo

tank

Our Project Record

Bolted and welded tanks delivered since 2003

Storage tanks, bins and silos for operators, EPC contractors and fabricators across Asia, the Middle East, Africa and Australia — from potable and fire water to bitumen, grain and process storage.

2003Designing since
12Countries delivered into
50+Named client organisations
14Design codes worked to

Selected projects

Treated waste water storage tankØ45.54 m × 8.45 mDar Al Handasah, EgyptAWWA D103
Raw & fire water storage tankØ9.88 m × 18.63 mAker Powergas Pvt LtdAWWA D103
Filtered water storage tankØ15.47 m × 13.3 mAker Powergas Pvt LtdAWWA D103
Fire water storage tankØ12.25 m × 5.3 mGorkha Brewery, NepalAS 2304
GFS tankØ7.6 m × 7.3 mR P LtdAWWA D103
Zincalume water storage tankØ7.0 m × 4.2 mLarsen & Toubro, IndiaAS 2304
Zincalume water storage tankØ8.05 m × 4.2 mNCC Ltd, HyderabadAS 2304

Organisations we have delivered for

Larsen & Toubro
NCC
Aker Powergas
Zydus Cadila
Dar Al Handasah
Red Sea Development Company
Qatar Kentz
Lars Enviro

Codes we design to

API 650
API 620
AWWA D103
AS 2304
EN 1993-4-1

We stay on a project until the client signs it off. Revisions, clarifications and site queries are part of the job, not an extra. That has been the practice on every project since 2003.
