Description
What Beam Deflection Calculation calculates
Beam Deflection Calculation is a professional structural and civil engineering calculation tool that takes 9 engineering inputs and produces 6 verified results. The calculation follows AISC 360 / IS 800. Every formula is traceable to the governing standard clause, and every result is checkable against a worked example.
Input parameters
You provide these values from your project data:
| Parameter | Symbol | Unit | Typical value |
|---|---|---|---|
| Span Length | input_D7 |
mm | 6000 |
| UDL (Uniform Dist. Load) | input_D8 |
kN/m | 10 |
| Central Point Load | input_D9 |
kN | 50 |
| Moment of Inertia (Ixx) | input_D11 |
cm⁴ | 8603 |
| Section Modulus (Zxx) | input_D12 |
cm³ | 573.6 |
| Young’s Modulus | input_D13 |
MPa | 200000 |
| Yield Stress | input_D14 |
MPa | 250 |
| Allowable Bending Stress | input_D15 |
MPa | 165 |
Calculation results
The spreadsheet calculates these results from your inputs:
- Deflection Poi
- Total Deflectio
- Allowable Defle
- Stress Check Ra
- Deflection Chec
- A32
Governing standards
This calculation is built to comply with:
- AISC 360 / IS 800
Each formula references the applicable code clause so your checker can trace every step back to the standard.
What you get
- Excel calculation file (.xlsx) — fully unlocked formulas, 12 calculation steps, clear input/output layout
- Worked example — realistic inputs with expected outputs so you can validate against a known case
- Code references — every formula cross-referenced to the applicable standard clause
- Email support — reply within 24 hours for questions about the spreadsheet
Try before you buy
Use the free calculator above to check your values with a single set of inputs. For unlimited inputs, editable formulas, and a professional calculation report, purchase the full spreadsheet at INR 999.
