horizontal vessel calculation


All calculations are created by 3D-LABS, easy to execute any projects with our work procedure. after your payment, click download will be downloaded in spreadsheet format….

A pressure vessel is considered as any closed vessel that is capable of storing a pressurized fluid, either internal or external pressure, regardless of their shape and dimensions.it is a container designed to hold gases or liquids at a pressure substantially different from the ambient pressure.   The fluid being stored may undergo a change of state inside the pressure veesel.in this calculation material selection is major factor to design the vessel. May properties affect the vessel due to high pressure or liquid. The internal design pressure is 49.783psig when used in the pressure calculation this is the MAWP. The internal radius is 59.055in,the allowable stress is 17100psi,longitudinal joint efficiency is 0.85.the thickness of O/D based the same properties is included.
