Wind Force on Horizontal Vessel Calculation
Engineering Spreadsheet — Instant Download
What This Spreadsheet Does
Calculates wind loading on horizontal pressure vessels per ASCE 7 and other applicable wind codes. Output feeds saddle support design, anchor design, and overall vessel stability checks for above-grade installed vessels.
What’s Inside the Excel File
- Inputs — vessel OD, length, elevation above grade, basic wind speed, exposure category, importance factor, topographic factor
- Velocity pressure calculation per ASCE 7
- Drag coefficient for horizontal cylinder per ASCE 7 Figure 29.5
- Wind force — total and per unit length
- Overturning moment at saddles
- Lateral reactions at fixed and sliding saddles
- Anchor bolt tension from wind
Who This Is For
- Pressure vessel design engineers
- Structural engineers on vessel foundation design
- EPC mechanical teams
- Plant designers in hurricane-prone or high-wind regions
Codes & Standards Referenced
- ASCE 7 — Minimum Design Loads and Associated Criteria for Buildings and Other Structures
- ASCE 7 Chapter 29 — Other Structures and Building Appurtenances
How It Works
| 1 | Purchase — secure payment |
| 2 | Download — instant Excel access |
| 3 | Enter Values — vessel and wind data |
| 4 | Get Results — wind force, reactions, anchor loads |
File Format & Compatibility
Microsoft Excel (.xlsx). Opens in Excel 2016+, Excel 365, Google Sheets. No macros, no locked cells.
What You Get After Payment
- ✅ Instant download (also emailed)
- ✅ Lifetime access
- ✅ Engineer email support
- ✅ 7-day refund if file fails to open
