This Foundation Fillet Weld En 1993-1-8 Calculation spreadsheet from 3D-LABS follows AISC standards and gives instant, checkable results for practising engineers — no manual derivation required.
Foundation Fillet Weld EN 1993-1-8 Calculation
This Foundation Fillet Weld EN 1993-1-8 Calculation — Eurocode Weld Excel spreadsheet provides a complete, code-compliant engineering solution.
Engineering Spreadsheet — Instant Download
What This Spreadsheet Does
Designs fillet welds at foundation and structural connections per Eurocode 3 Part 1-8 (EN 1993-1-8). Uses the directional method to check combined normal and shear stresses in the weld throat.
What’s Inside the Excel File
- Inputs — weld leg size, throat thickness, weld length, applied F⊥, F∥, V; parent material grade
- Throat stress decomposition — σ⊥, τ⊥, τ∥
- EN 1993-1-8 directional method check — Eq. 4.1 combined stress
- Simplified method check — Eq. 4.4 alternative
- Utilization ratio against allowable
- Clause references on every cell
