Description
What Site Levelling — Cut & Fill Mass-Haul Diagram calculates
Site Levelling — Cut & Fill Mass-Haul Diagram is a professional engineering calculation tool that takes 13 engineering inputs and produces 6 verified results. Every formula is traceable to the governing code clause, and every result is checkable against the worked example.
Input parameters
You provide these values from your project data:
| Parameter | Symbol | Unit | Example value |
|---|---|---|---|
| Sta 0+000 cut | input_D13 | m³ | 500 |
| Sta 0+100 cut | input_D14 | m³ | 800 |
| Sta 0+200 cut | input_D15 | m³ | 300 |
| Sta 0+300 fill | input_D16 | m³ | -700 |
| Sta 0+400 fill | input_D17 | m³ | -1200 |
| Sta 0+500 fill | input_D18 | m³ | -500 |
| Sta 0+600 cut | input_D19 | m³ | 400 |
| Sta interval | input_D20 | m | 100 |
| Bulking factor (cut→loose) | input_D22 | — | 1.2 |
| Compaction factor (fill→compacted) | input_D23 | — | 0.85 |
| Free-haul distance | input_D24 | m | 500 |
| Cost per m³ direct | input_D25 | ₹ | 80 |
| … plus 1 more input parameters | |||
Calculation results
The spreadsheet produces these verified outputs from your inputs:
- Avg Haul Dist
- Overhaul Dist
- Direct Cost
- Overhaul Cost
- Total Cost
- Verdict
What you receive
- Excel calculation file (.xlsx) — fully unlocked formulas, 33 calculation steps, clear input/output layout
- Worked example — realistic engineering values with expected outputs for independent verification
- Free online calculator — try your values instantly using the calculator above before purchasing
- Engineering support — email info@3d-labs.com for questions about inputs, methodology, or results
Try before you buy
Use the free calculator above to check your values with a single set of inputs. For unlimited calculations, editable formulas, and a professional calculation report, purchase the full spreadsheet at ₹999. One payment, lifetime access, no subscription.
