Description
What Jacket Structure In-Place Strength Check (API RP 2A) calculates
Jacket Structure In-Place Strength Check (API RP 2A) is a professional oil and gas engineering calculation tool that takes 10 engineering inputs and produces 6 verified results. Every formula is traceable to the governing code clause, and every result is checkable against the worked example.
Input parameters
You provide these values from your project data:
| Parameter | Symbol | Unit | Example value |
|---|---|---|---|
| Tubular OD D | input_D13 | mm | 914 |
| Wall thickness t | input_D14 | mm | 25 |
| Effective length KL | input_D15 | m | 12 |
| Yield strength Fy | input_D16 | MPa | 345 |
| Young's modulus E | input_D17 | MPa | 200000 |
| Axial compression Pu | input_D19 | kN | 6000 |
| Bending Mu_y | input_D20 | kNยทm | 400 |
| Bending Mu_z | input_D21 | kNยทm | 200 |
| Hydrostatic head h_hyd | input_D22 | m | 80 |
| Resistance factor ฯ | input_D23 | โ | 0.85 |
Calculation results
The spreadsheet produces these verified outputs from your inputs:
- Allowable Axial
- Allowable Momen
- Axial Ur
- Bending Ur
- Combined Ur
- Verdict
What you receive
- Excel calculation file (.xlsx) โ fully unlocked formulas, 29 calculation steps, clear input/output layout
- Worked example โ realistic engineering values with expected outputs for independent verification
- Free online calculator โ try your values instantly using the calculator above before purchasing
- Engineering support โ email info@3d-labs.com for questions about inputs, methodology, or results
Try before you buy
Use the free calculator above to check your values with a single set of inputs. For unlimited calculations, editable formulas, and a professional calculation report, purchase the full spreadsheet at โน3,899. One payment, lifetime access, no subscription.
