Description
This Analog Circuit Design eBook from 3D-LABS is written for engineers and students who want a clear, practical reference they can apply immediately.
Analog Circuit Design — Real Components, Real Tolerances covers practical analog design with real-world component variation – op-amp offset, bias current, CMRR, PSRR, bandwidth effects – using worst-case and Monte Carlo analysis.
What standards does this book reference?
IEC 60748-3-3 op-amp parameter definitions, IPC-2221B PCB trace resistance temperature effects, JEDEC JESD51 component thermal characterisation, and IEEE 1241-2010 ADC linearity testing methods.
What op-amp non-ideal parameters are systematically analysed?
Vos: output error = Vos*(1+RF/RIN), drift = Vos_TC*delta-T*gain. IB: V_error = IB*R_source, compensated by R_comp=RF||RIN at non-inverting input. CMRR: error = Vcm/CMRR. PSRR: error = delta-Vsupply/PSRR. Bandwidth: f_-3dB = GBW/(1+RF/RIN).
What worst-case tolerance analysis is used?
RSS: total error = sqrt(sum of individual errors squared). Monte Carlo: 10,000 iterations with component values drawn from Gaussian (sigma=tolerance/3 for 99.7% coverage). Circuit yield = percentage of iterations meeting specification.
How do I access this book after purchase?
eBook PDF: Instant download via email and 3D-LABS dashboard. Paper Book: Printed and shipped to India.
What’s Included
An instant PDF download covering the core concepts, practical examples, and key references — ready to read on any device.
