Description
This Design And Analysis Skid Structure eBook from 3D-LABS is written for engineers and students who want a clear, practical reference they can apply immediately.
Design and Analysis Skid Structure covers complete structural engineering of process equipment skid frames — loading analysis, AISC/IS 800 beam and column design, base frame connections, anchor bolt calculation for dynamic and seismic loads, and grout specification. Written for structural and mechanical engineers in EPC and fabrication firms.
What standards does this book reference?
AISC 360-22 (structural steel by LRFD), IS 800:2007 (Indian structural steel limit state design), IS 875 Part 3:2015 (wind loads for outdoor equipment), IS 1893 Part 4:2015 (seismic loads for industrial structures), and ACI 318-19 Chapter 17 (anchor design in concrete for anchor bolt calculations).
What skid beam design formula is used for equipment loads?
LRFD per AISC 360-22: factored load wu = 1.2DL + 1.6LL (kN/m). Maximum moment Mu = wu x L^2/8 for simply supported beam. Required section modulus Zx = Mu / (phi-b x Fy), phi-b = 0.9, Fy = 250 MPa for IS 2062 E250. Select ISMB section from IS 808:1989. Shear check: Vu = wu x L/2, phi-v x Vn = 0.9 x 0.6 x Fy x Aw >= Vu.
What anchor bolt design is covered for seismic loads?
Anchor bolt tension under seismic overturning: T_bolt = (M_OT – W_equip x a) / (N_tension x d_bolt), where M_OT is overturning moment (F_seismic x H_cg for IS 1893 zone III at 0.16g horizontal acceleration), W_equip is stabilising weight, a is moment arm, and d_bolt is bolt pattern dimension. Concrete breakout strength per ACI 318-19 Section 17.6: N_cbg = f(area, eccentricity, edge, cracking, Nb), where Nb = k_c x sqrt(fc) x h_ef^1.5.
How do I access this book after purchase?
eBook PDF: Instant download via email and 3D-LABS dashboard. Paper Book: Printed and shipped to India.
What’s Included
An instant PDF download covering the core concepts, practical examples, and key references — ready to read on any device.
Related Reading
- Applied Strength: Tank, Vessel and Skid Edition
- Statics for Real Structures — From Free Body to Foundation
- Skid Lifting Lug Rope-Angle Calculation — Equipment Skid Excel
Download the Design and Analysis Skid Structure from 3D-LABS for instant, verifiable results.
About Design and Analysis Skid Structure
Design and Analysis Skid Structure is part of the 3D-LABS Engineering series — a focused e-book library for engineers, students, and technical professionals. This title covers engineering fundamentals, industry practices, and applied problem-solving, with worked examples and industry-current best practices drawn from real engineering projects.
Written by practising 3D-LABS engineers and reviewed by senior specialists, Design and Analysis Skid Structure is designed to move you from concept to competence quickly — not to be a comprehensive academic reference, but a working reference you actually use.
Who Design and Analysis Skid Structure is for
Design and Analysis Skid Structure is written for engineers, students, and technical professionals. If you are:
- An early-career engineer wanting to accelerate your practical knowledge in engineering.
- An experienced practitioner looking for a compact reference on current practices.
- A student preparing for engineering exams, interviews, or your first professional role.
- A manager or team lead wanting to level-set your team on engineering fundamentals.
Then Design and Analysis Skid Structure will earn its price back in the first project or exam you apply it to.
What is included in your download
- The complete PDF e-book — DRM-free, fully searchable, print-friendly formatting.
- Worked examples — real-world calculations, drawings, or case studies interspersed through the text.
- Reference charts and tables — quick-lookup material you will return to on the job.
- Further reading recommendations — curated pointers to codes, standards, and complementary resources.
- Free updates — when we revise the book, you get the updated PDF at no extra cost. We notify you by email.
Pricing and delivery
Design and Analysis Skid Structure is priced at ₹6,615 (USD equivalent shown in cart). Delivery is instant — after payment, the download link is emailed to you and available in your account. No subscriptions, no hidden fees, no expiring access.
Payment methods: Cashfree (Indian customers) or PayPal International (customers outside India). Bulk licensing available for corporate training programmes and educational institutions — contact sales@3d-labs.com.
