WRC 297 Nozzle Stress (alternative method) β method, governing standards and output schedule
The WRC 297 Nozzle Stress (alternative method) calculation determines the local membrane and bending stresses induced in a cylindrical or spherical shell by external loads transmitted through an attached nozzle, and compares the resulting stress intensities against the code allowables for local and secondary stress. It is applied during detailed design, during design verification by a second engineer, and again during in-service assessment when the operating basis changes. Because every intermediate quantity is reported rather than only the final answer, the calculation can be checked line by line against the governing standard without re-deriving it.
This 3D-LABS workbook is built to WRC 297. You supply 4 inputs and the sheet reports 5 results, with every formula left visible so each figure can be traced to the clause it comes from.
Method of calculation
Dimensionless geometric parameters are formed from the shell and attachment dimensions, curves of the WRC bulletin are entered to obtain the stress concentration coefficients, and membrane plus bending stresses are superposed at the four cardinal points of the attachment for radial load, circumferential and longitudinal moments and torsion. The resulting stress intensities are combined with the general primary membrane stress from internal pressure.
Governing standards and references
- WRC 297 β WRC Bulletin 297 local stresses in cylindrical shells due to external loadings
- WRC 537 / WRC 107 β Welding Research Council Bulletin 537, which supersedes Bulletin 107, for local stresses in
Each formula cites the clause it comes from on the same row as the result it produces, so a reviewer can check the sheet line by line against the standard.
Acceptance criteria
For the calculation to be reported as acceptable, the maximum combined stress intensity must remain within the allowable limits for local primary membrane plus bending and for secondary stress, evaluated per the applicable division of Section VIII.
Who uses this calculation
This calculation is used by pressure vessel stress analysts, piping engineers resolving nozzle load allowables, and reviewers reconciling pipe stress output with vessel capability.
