ASHRAE Duct Sizing — Equal Friction & Velocity Method Excel — method, governing standards and output schedule
The ASHRAE Duct Sizing — Equal Friction & Velocity Method Excel calculation establishes the air flow and duct or equipment sizes needed to meet the space thermal and air-quality requirements, and reports the resulting fan static pressure and the governing design condition. It is applied during detailed design, during design verification by a second engineer, and again during in-service assessment when the operating basis changes. Because every intermediate quantity is reported rather than only the final answer, the calculation can be checked line by line against the governing standard without re-deriving it.
This 3D-LABS workbook is built to ASHRAE. You supply 10 inputs and the sheet reports 5 results, with every formula left visible so each figure can be traced to the clause it comes from.
Method of calculation
Space cooling load is built up from fabric conduction using cooling load temperature differences, solar gain, infiltration and internal gains, and the supply air flow follows from the sensible heat equation at the selected supply air temperature difference. Ducts are then sized by the equal-friction or static-regain method, fitting losses are added as equivalent lengths, and the index run establishes the fan external static pressure.
Governing standards and references
- ASHRAE — ASHRAE Handbook – Fundamentals and Applications
Each formula cites the clause it comes from on the same row as the result it produces, so a reviewer can check the sheet line by line against the standard.
Acceptance criteria
For the calculation to be reported as acceptable, the delivered air flow must meet the load and the minimum air change or fresh-air requirement, with duct velocities within the noise-related limits and the fan static pressure matched to the selected unit.
Who uses this calculation
This calculation is used by HVAC design engineers, cleanroom and pharmaceutical facility designers, and reviewers verifying air balance against specification.
What you receive
- Excel calculation file (.xlsx) — fully unlocked formulas and a clear input/output layout
- Worked example — realistic engineering values with expected outputs so you can verify the sheet against a known case
- Code references — every formula cross-referenced to ASHRAE
- Email support — write to info@3d-labs.com with questions about inputs, methodology or results
Delivery and licence
Instant download after payment at ₹1,599. One payment, lifetime access, no subscription. The workbook is a design aid — results must be verified by a qualified engineer before use.
