design calculation of fire water storage tank

80,000.00

In this calculation we are going to design firewater storage tank, for that I am using AWWA D103-09 specification code. Tank properties are (tank diameter D= 6870mm, tank height h = 8450mm, overflow height H =8140mm). this design of storage tank made for the location of saudi.in this calculation we are taking design parameters  , wind load as 45 m/s, and seismic zone II , in this calculation we have shell design , roof design, wind Girder ,bolt design and  anchor bolt design. All the design done by AWWA D 103-09.

2. design calculation of fire water storage tank

In this calculation we are going to design firewater storage tank, for that I am using AS 2304 specification code. Tank properties are (tank diameter D= 12250mm, tank height h = 5300mm, overflow height H =4842mm). this design of storage tank made for the location of saudi.in this calculation we are taking design parameters  , wind load as 55 m/s, and seismic zone IV , in this calculation we have structural design actions , seismic design, wind buckling ,bolt design and  anchor bolt design. All the design done by AS 2034.
