design calculation of etp bio-reactor tank

80,000.00

In this calculation we are going to design ETP BIO-REACTOR TANK, for that I am using AWWA D103-09 specification code. Tank properties are (tank diameter D= 6870mm, tank height h = 8450mm, overflow height H =7600mm). this design of storage tank made for the location of Kanpur India .in this calculation we are taking design parameters  , wind load as 47 m/s, and seismic zone III , in this calculation we have shell design , roof design, wind Girder ,bolt design and  anchor bolt design. All the design done by AWWA D 103-09.
