Craftsman House Plan-304
₹17,000.00
This design is open to customization!
Share your envisioned modifications with us, allowing us to generate a design service estimate for you. Simply press the button to send your pricing request. Please mention plan number.
PLAN NUMBER:- 304
PLAN DESCRIPTION
Basic Features
Ground Floor
DRAWING – 1
BED ROOM – 2
REST ROOM – 2
KITCHEN & DINING -1
CAR GARAGE – 1
Dimensions
Height : 10′
Area
Total 2132 Sq/Ft
Ground Floor 1554 sq/ft
WHAT’S INCLUDED IN THIS PLAN SET
- Cover Sheet – May include index, front view of home, definitions, etc.
- Dimensioned Floor Plan –
- Exterior Views – Two exterior views of the residence with other miscellaneous details.
- Roof Plan – Birds eye view showing all ridges, valleys and other necessary information
ADDITIONAL WORK PRICING
Plan Options
Foundation Plan
$80
Usually comprises a foundation plan complete with dimensions and specific footing information.
Electrical Plan
$80
Shows all essential electrical components, including lighting fixtures, outlets, and other required items, which may also be indicated on the Dimensioned Floor Plan
Wall Section
$80
Elaboration on wall materials and their construction.
Building Section
$30
Cross-section of the residence providing vital framing details and miscellaneous data.
Additional Construction Sets
$80
Extra printed copies of the blueprint
Audio Video Design
$80
Get an overlay sheet indicating recommended positions for audio and video component.
Material List
$80
Access a construction materials spreadsheet required for building the foundation of your new home. Please be aware that the materials list does not account for additional options like alternative foundations and framing.
