Anchor to Concrete CSA A23.3 Calculation

This Anchor to Concrete CSA A23.3 Calculation — Canadian Concrete Anchorage Excel spreadsheet provides a complete, code-compliant engineering solution.

Engineering Spreadsheet — Instant Download

What This Spreadsheet Does

Sizes cast-in and post-installed anchors in concrete to Canadian code. Built for structural and mechanical engineers on Canadian projects, EPC engagements serving Canadian clients, or any work where CSA A23.3 governs concrete anchorage.

What’s Inside the Excel File

• Inputs — applied tension, shear, moment; concrete f’c; anchor diameter and grade; embedment depth; edge distance; spacing; group configuration
• CSA A23.3 Annex D checks — steel strength in tension, concrete breakout in tension, pullout, side-face blowout, concrete breakout in shear, pryout
• Combined tension + shear interaction per Annex D
• Utilization ratios — pass/fail flag against governing limit state
• Drop-in summary block for your stamped calculation report
• Clause references on every formula cell

Who This Is For

• Structural engineers on Canadian industrial, commercial, infrastructure projects
• Mechanical engineers sizing equipment, vessel, skid anchorage on Canadian sites
• EPC teams delivering to Canadian Oil & Gas, mining, energy clients
• Freelance consultants billing CSA-compliant anchorage design

Codes & Standards Referenced

• CSA A23.3 — Design of Concrete Structures
• CSA A23.3 Annex D — Anchorage

How It Works

File Format & Compatibility

Microsoft Excel (.xlsx). Opens in Excel 2016+, Excel 365, Google Sheets. No macros, no locked cells, no watermarks.

What You Get After Payment

• ✅ Instant download (also emailed)
• ✅ Lifetime access
• ✅ Engineer email support
• ✅ 7-day refund if file fails to open
