Pipe Repair Sleeve / Composite Wrap Sizing β method, governing standards and output schedule
The Pipe Repair Sleeve / Composite Wrap Sizing sizes the protective or insulating system required to hold a surface at the specified condition over the design life, reporting the current demand, anode mass or insulation thickness needed. It is applied during detailed design, during design verification by a second engineer, and again during in-service assessment when the operating basis changes. Because every intermediate quantity is reported rather than only the final answer, the calculation can be checked line by line against the governing standard without re-deriving it.
This 3D-LABS workbook is built to DNV-RP-B401. You supply 5 inputs and the sheet reports 6 results, with every formula left visible so each figure can be traced to the clause it comes from.
Method of calculation
For cathodic protection the current demand is the product of the surface area to be protected, the current density appropriate to the environment and coating condition, and a coating breakdown factor that grows over the design life; anode mass follows from that current and the design life through the consumption rate and utilisation factor. For insulation the thickness is iterated until the calculated heat loss and surface temperature both satisfy the energy and personnel-protection criteria.
Governing standards and references
- DNV-RP-B401 β DNV-RP-B401 Cathodic protection design
- ASTM C680 β ASTM C680 Practice for Estimate of Heat Gain or Loss Through Insulation
Each formula cites the clause it comes from on the same row as the result it produces, so a reviewer can check the sheet line by line against the standard.
Acceptance criteria
For the calculation to be reported as acceptable, the protective current must satisfy the final-year demand with the coating fully broken down, and insulation thickness must hold both heat loss and touch temperature within the specified limits.
Who uses this calculation
This calculation is used by corrosion and materials engineers, piping and mechanical engineers specifying insulation, and reviewers checking protection system designs.
What you receive
- Excel calculation file (.xlsx) β fully unlocked formulas and a clear input/output layout
- Worked example β realistic engineering values with expected outputs so you can verify the sheet against a known case
- Code references β every formula cross-referenced to DNV-RP-B401
- Email support β write to info@3d-labs.com with questions about inputs, methodology or results
Delivery and licence
Instant download after payment at βΉ4,199. One payment, lifetime access, no subscription. The workbook is a design aid β results must be verified by a qualified engineer before use.
