Design calculation of filtered water storage tank


Quality assuranceAll calculations are created by 3D-LABS, easy to execute any projects with our work procedure. after your payment, click download will be downloaded in spreadsheet format….

In this calculation we are going to design filtered water storage tank, for that I am using AWWA D103-09 specification code. Tank properties are (tank diameter D= 15470mm, tank height h = 15025mm, overflow height H =14410mm). this design of storage tank made for the location of Bharuch gujrat.in this calculation we are taking design parameters, wind load as 44 m/s, and seismic zone II , in this calculation we have shell design , roof design, bolt design and  anchor bolt design. All the design done by AWWA D 103-09.
