Cam Profile Design (Kinematic Synthesis) — method, governing standards and output schedule
The Cam Profile Design (Kinematic Synthesis) calculation sizes a power transmission or motion component for the transmitted load, speed and required service life, reporting the capacity margin and the governing failure mode. It is applied during detailed design, during design verification by a second engineer, and again during in-service assessment when the operating basis changes. Because every intermediate quantity is reported rather than only the final answer, the calculation can be checked line by line against the governing standard without re-deriving it.
This 3D-LABS workbook is built to VDI 2143. You supply 4 inputs and the sheet reports 5 results, with every formula left visible so each figure can be traced to the clause it comes from.
Method of calculation
The transmitted torque is derived from power and speed and amplified by a service factor for the duty and shock character of the application. Component capacity is then evaluated by the recognised rating method for the element, whether the bending and contact stress formulations for gear teeth, the dynamic equivalent load and L10 life expression for rolling bearings, the combined torsion-and-bending fatigue check with the Soderberg or Goodman criterion for shafts, or the catalogue power rating with correction factors for belt and chain drives.
Governing standards and references
- VDI 2143 — VDI 2143 Motion laws for cam mechanisms
- VDI 2142 — VDI 2142 Design of cam mechanisms
- Norton Cam Design — Norton, Cam Design and Manufacturing Handbook
Each formula cites the clause it comes from on the same row as the result it produces, so a reviewer can check the sheet line by line against the standard.
Acceptance criteria
For the calculation to be reported as acceptable, the rated capacity must exceed the design load after all service factors, the predicted life must meet or exceed the specified design life, and operating speed must stay clear of the calculated critical speed by the conventional margin.
Who uses this calculation
This calculation is used by machine designers and mechanical engineers selecting drive components, maintenance engineers investigating failures, and reviewers checking vendor selections.
What you receive
- Excel calculation file (.xlsx) — fully unlocked formulas and a clear input/output layout
- Worked example — realistic engineering values with expected outputs so you can verify the sheet against a known case
- Code references — every formula cross-referenced to VDI 2143
- Email support — write to info@3d-labs.com with questions about inputs, methodology or results
Delivery and licence
Instant download after payment at ₹1,299. One payment, lifetime access, no subscription. The workbook is a design aid — results must be verified by a qualified engineer before use.
