Piping Stress Analysis

Description

This Piping Stress Analysis eBook from 3D-LABS is written for engineers and students who want a clear, practical reference they can apply immediately.

Piping Stress Analysis covers ASME B31.3 piping flexibility, thermal expansion analysis, and pipe stress qualification — sustained stress, thermal expansion stress, and occasional load checks — with Caesar II modelling methodology and support location optimisation. Written for piping stress engineers and plant mechanical engineers.

What ASME B31.3 stress checks does this book cover?

ASME B31.3-2022 Clause 302.3.5 SIF calculation, Clause 319.4.1 sustained stress check (SL <= Sh), Clause 319.4.2 thermal expansion stress (SE <= SA = f x (1.25Sc + 0.25Sh)), and Clause 319.4.4 occasional loads (sustained + 0.33Sh for wind/seismic). Support design: variable spring hangers for hot lines (spring constant k, operating load W, travel delta = thermal displacement), rigid supports for cold lines.

What is the ASME B31.3 sustained stress equation?

SL = (P x Do) / (4 x t) + (0.75 x i x MA) / Z, where P is design pressure (MPa), Do is pipe outside diameter (mm), t is nominal wall thickness (mm), i is stress intensification factor (SIF from B31.3 Appendix D), MA is resultant moment from sustained loads (N-mm), and Z is section modulus (pi x D^3/32 for solid section in mm^3). SL must be <= Sh (hot allowable stress from ASME II Part D at operating temperature).

What Caesar II modelling methodology is covered?

Caesar II model setup: pipe specification (OD, wall, material, operating temperature, design pressure), support modelling (anchors, guides, line stops, spring hangers), and load cases (sustained, thermal, occasional). Displacement analysis: thermal anchor movement input at equipment nozzles. Stress report review: identify failed load cases, optimise support locations to reduce overstress at fittings. Node spacing: maximum 3D for straight runs, additional nodes at concentrated loads and bends.

How do I access this book after purchase?

eBook PDF: After your payment is confirmed, our team emails the PDF to the address on your order. No shipping wait, and no subscription — if you need another copy later, email info@3d-labs.com and we will resend it. Paper Book: Printed and shipped worldwide. Shipping within India is free; international shipping is charged at checkout.
