design calculation of silo

₹90,000.00

In this calculation we are going to design SILO, for that I am using EN 1993, 1991, 1998 specification code. Silo properties are (tank diameter D= 16600mm, tank height h = 17920mm). This design of silo made for the location of BIHAR.in this calculation we are taking design parameters, wind SPEED as 144 Km/h, and seismic zone IV, in this calculation we take wall sheet material is zincalume and A36 structural material. All the design done by EN 1991.4, 1993.4.1, 1998.4 code.
