Pig Launcher ASME B 31.4 Design

$29.00

All calculations are created by 3D-LABS, easy to execute any projects with our work procedure. after your payment, click download will be downloaded in spreadsheet format….

    If you need any specific calculation, let us know!

    If you require any additional calculations or assistance, please do not hesitate to contact us. Our team is ready to provide the necessary support to meet your specific needs.

    For more information or to request personalized support, please reach out to us at info@3d-labs.com or call us at 0091-9843511204.

    Trust 3D-LABS for accurate calculations and unwavering support throughout your project’s lifecycle.

    The pig launchers(Input values are your choice) and receivers were designed for a coal-bed methane gas production facility in Colorado. They are equipped with an integral safety locking system which works on the principle of mechanical key interlocking (transfer of keys). This system avoids serious injuries from human error and insures safety of personnel. One starter key per launcher/receiver is kept in a box located in the control room. Each lock is executed with two keys. When the first valve is opened with this starter key, it releases the second key. This key is transferred to next valve which releases second key from that valve and so on and so forth. This process guides the operator through the specified sequence for opening and closing valves with unique a key for each step.
