Description
What GLS Tank – AWWA D103 Design calculates
GLS Tank – AWWA D103 Design is a professional engineering design calculation tool that takes 9 engineering inputs and produces 6 verified results. The calculation follows AWWA (Water Works), AWWA D103 (Bolted Steel Tanks). Every formula is traceable to the governing standard clause, and every result is checkable against a worked example.
Input parameters
You provide these values from your project data:
| Parameter | Symbol | Unit | Typical value |
|---|---|---|---|
| Design capacity Vreq | input_D13 |
m³ | 500 |
| Tank diameter D | input_D14 |
m | 9.5 |
| Tank height H | input_D15 |
m | 7 |
| Panel arc width | input_D16 |
m | 2.45 |
| Panel course height | input_D17 |
m | 1 |
Calculation results
The spreadsheet calculates these results from your inputs:
- Allowable Stres
- Bolts Per Seam
- Panels Per Cour
- Total Panels
- Calc D64
- Hoop Check
Governing standards
This calculation is built to comply with:
- AWWA (Water Works)
- AWWA D103 (Bolted Steel Tanks)
Each formula references the applicable code clause so your checker can trace every step back to the standard.
What you get
- Excel calculation file (.xlsx) — fully unlocked formulas, 28 calculation steps, clear input/output layout
- Worked example — realistic inputs with expected outputs so you can validate against a known case
- Code references — every formula cross-referenced to the applicable standard clause
- Email support — reply within 24 hours for questions about the spreadsheet
Try before you buy
Use the free calculator above to check your values with a single set of inputs. For unlimited inputs, editable formulas, and a professional calculation report, purchase the full spreadsheet at INR 26,000.
