FEA for Practising Engineers — ANSYS Workbench Edition

Description

This Fea For Practising Engineers eBook from 3D-LABS is written for engineers and students who want a clear, practical reference they can apply immediately.

FEA for Practising Engineers — ANSYS Workbench Edition covers finite element analysis using ANSYS Workbench 2024 R1 for structural, thermal, and fatigue analysis — from mesh generation and boundary conditions through convergence, post-processing, and formal result validation for pressure vessel, structural steel, and rotating machinery applications.

What standards does this book reference?

ASME Section VIII Div 2 Part 5 (design by analysis — FEA basis for pressure vessels), ASME VIII-2 Annex 5-D (elastic-plastic analysis), EN 13445-3 Annex B (FEA for unfired pressure vessels in Europe), and AISC 360-22 Appendix 1 (design by inelastic analysis for structural steel).

What mesh convergence criteria are used?

Run analysis at three mesh sizes (coarse, medium, fine with 2:1 element size ratio between steps). Monitor von Mises stress at maximum stress location. Accept convergence when stress change between medium and fine mesh is less than 5%. ANSYS Workbench quality metrics: orthogonal quality minimum greater than 0.1, skewness maximum less than 0.9, aspect ratio maximum less than 20. Singularity at sharp re-entrant corners (stress diverges with mesh refinement) — replace with fillet radius.

What FEA validation approach is used?

Three-tier validation: (1) Sanity check — reaction forces equal applied loads; (2) Benchmark comparison — Lame cylinder analytical hoop stress: sigma-theta = P x Ri^2 x (Ro^2 + r^2) / (r^2 x (Ro^2 – Ri^2)) compared with ANSYS result; (3) Code comparison — ANSYS membrane stress compared with ASME VIII-1 UG-27 analytical formula. Acceptable deviation less than 5% documented in formal calculation note.

How do I access this book after purchase?

eBook PDF: After your payment is confirmed, our team emails the PDF to the address on your order. No shipping wait, and no subscription — if you need another copy later, email info@3d-labs.com and we will resend it. Paper Book: Printed and shipped worldwide. Shipping within India is free; international shipping is charged at checkout.

Contents

1. How to Use This Book and the Example Models — p. 1–12
2. What FEA Actually Solves: Stiffness, Loads and Assumptions — p. 13–34
3. Workbench Project Schematic and Engineering Data Setup — p. 35–54
4. Geometry Preparation and Defeaturing in SpaceClaim — p. 55–78
5. Meshing: Element Types, Sizing and Quality Metrics — p. 79–106
6. Contacts, Connections and Joints in Assemblies — p. 107–132
7. Boundary Conditions and Load Cases That Match Reality — p. 133–156
8. Linear Static Analysis and Reading the Stress Results — p. 157–180
9. Mesh Convergence, Singularities and Result Validation — p. 181–202
10. Modal and Harmonic Analysis for Vibration Problems — p. 203–226
11. Steady-State and Transient Thermal with Thermal Stress — p. 227–248
12. Nonlinear Analysis: Plasticity, Large Deflection and Contact — p. 249–270
13. Fatigue Life Estimation and Design Margins — p. 271–288
14. Reporting Results: Hand Calculations, Checklists and Sign-Off — p. 289–300

What’s Included

An instant PDF download covering the core concepts, practical examples, and key references — ready to read on any device.

Related Reading

• FEA Engineer Training
• Finite Element Analysis Basics
• Pressure Vessel Design — ASME Section VIII Walk-Through

Download the FEA for Practising Engineers — ANSYS Workbench Edition e-book from 3D-LABS — instant PDF access with lifetime re-downloads.
