AWWA Tank Shell and Loads Calculation — Bolted & Welded Water Tank Excel

Description

This Awwa Tank Shell And Loads Calculation spreadsheet from 3D-LABS follows API standards and gives instant, checkable results for practising engineers — no manual derivation required.

AWWA Tank Shell and Loads Calculation

This AWWA Tank Shell and Loads Calculation — Bolted & Welded Water Tank Excel spreadsheet provides a complete, code-compliant engineering solution.

This AWWA Tank Shell and Loads Calculation — Bolted & Welded Water Tank Excel spreadsheet provides a complete, code-compliant engineering solution.

Engineering Spreadsheet — Instant Download

What This Spreadsheet Does

Calculates shell course thicknesses and the full load envelope for AWWA-compliant water storage tanks — bolted (D-103) and welded (D-100) configurations. Built for water-sector design engineers, municipal infrastructure consultants, and EPC teams on potable and raw water projects.

What’s Inside the Excel File

• Inputs — tank diameter, height, liquid level, specific gravity, wind speed, seismic site class, allowable stress, joint efficiency
• Shell thickness per course for hydrostatic + design loads
• Load combinations — dead, hydrostatic, wind, seismic per AWWA
• Bolted vs welded toggle for joint efficiency selection
• Utilization ratios per course
• Drop-in summary table for design report

Who This Is For

• Water-sector design engineers
• Municipal infrastructure consultants
• EPC teams on potable and raw water projects
• Bolted tank manufacturers and detailers

Codes & Standards Referenced

• AWWA D-100 — Welded Carbon Steel Tanks for Water Storage
• AWWA D-103 — Factory-Coated Bolted Carbon Steel Tanks for Water Storage

How It Works

File Format & Compatibility

Microsoft Excel (.xlsx). Opens in Excel 2016+, Excel 365, Google Sheets. No macros, no locked cells.

What You Get After Payment

• ✅ Instant download (also emailed)
• ✅ Lifetime access
• ✅ Engineer email support
• ✅ 7-day refund if file fails to open

🌍 Trusted by engineers across 50+ countries · 📚 Part of 160+ engineering spreadsheets · 🛠 Support from qualified engineers

Frequently Asked Questions

Welded or bolted tanks?
Both — toggle between D-100 (welded) and D-103 (bolted) joint efficiencies.

Does it cover net section tension at bolted joints?
That check is in our dedicated AWWA D-103 net section tension sheet.

Custom version needed?
Request a custom quote.
