This Anchor Bolt Design For Cylindrical Tank Calculation spreadsheet from 3D-LABS gives instant, checkable results for practising engineers โ no manual derivation required.
What’s Included in This Spreadsheet
This spreadsheet calculates the anchor bolt design for cylindrical storage tanks subjected to wind and seismic loading. It applies structural and mechanical engineering standards to determine bolt size, spacing, and embedment requirements. Key inputs include tank dimensions, operating weight, wind speed, seismic zone, and material properties. Key outputs include required bolt size, number of bolts, pretension force, and base plate dimensions. Intended for mechanical and structural engineers, EPC contractors, and fabrication shops. Editable Excel format. Engineering support available โ contact 3D-LABS.
