PMSM and BLDC Motor Design for Traction

Description

This PMSM and BLDC Motor Design for Traction eBook from 3D-LABS is written for engineers and students who want a clear, practical reference they can apply immediately.

PMSM and BLDC Motor Design for Traction covers the electromagnetic, thermal and mechanical design of permanent-magnet traction machines for two-wheelers, three-wheelers and light passenger vehicles — from initial sizing and winding layout through flux weakening, demagnetisation limits and FEA verification.

What standards does this book reference?

IEC 60034-1 (rating and performance), IEC 60034-2-1 (efficiency determination from losses), IEC 60034-30-2 (efficiency classes for variable-speed AC motors), and AIS-041 for net power and maximum 30-minute power measurement on Indian electric vehicles.

How do PMSM and BLDC machines compare for traction?

PMSM has a sinusoidal back-EMF and is driven by field-oriented control; BLDC has a trapezoidal back-EMF and is driven by six-step commutation. PMSM gives lower torque ripple and lower acoustic noise at the cost of a more demanding controller and position feedback. BLDC is cheaper to drive but produces commutation torque ripple that is audible in low-speed urban duty.

How is a traction motor initially sized?

Torque scales with rotor volume: T = 2 σ V_r, where V_r = πD²L/4 and σ is the air-gap shear stress — typically 10 to 25 kPa for a totally enclosed PM traction machine and higher when liquid cooled. For a surface-mounted PM machine operated at i_d = 0, T = (3/2) p λ_m i_q, with p the pole-pair count and λ_m the magnet flux linkage.

How is the flux-weakening range determined?

Above base speed the drive injects negative d-axis current to hold terminal voltage within the inverter limit. The constant-power speed ratio follows from the characteristic current I_ch = λ_m / L_d: the closer I_ch sits to the rated current, the wider the usable field-weakening range. The book works a 48 V two-wheeler case and a 350 V passenger-car case through the voltage and current limit circles.

What limits continuous torque in Indian operating conditions?

Winding temperature and magnet demagnetisation, not peak current. Class H insulation allows a 180 °C winding hot-spot, while sintered NdFeB in SH grades begins to lose flux irreversibly well below that, so the magnet knee temperature usually sets the continuous rating. The book covers thermal paths for air-cooled hub motors and the duty cycles that matter in Indian traffic.

How do I access this book after purchase?

eBook PDF: Instant download via email and 3D-LABS dashboard. Paper Book: Printed and shipped to India.

Contents

1. Traction Motor Requirements and Duty Cycles — p. 1–20
2. Fundamentals of PMSM and BLDC Operation — p. 21–42
3. Magnetic Circuit Design and Material Selection — p. 43–64
4. Stator Design: Slots, Windings and Fill Factor — p. 65–86
5. Rotor Topologies: Surface, Interior and Spoke Magnets — p. 87–108
6. Analytical Sizing and Torque Estimation — p. 109–130
7. Finite Element Analysis and Design Iteration — p. 131–152
8. Losses, Efficiency Maps and Thermal Modelling — p. 153–174
9. Cooling Design and Insulation Class Selection — p. 175–196
10. Cogging Torque, Torque Ripple, Noise and Vibration — p. 197–218
11. Control Strategies: FOC, Field Weakening and Sensorless Operation — p. 219–240
12. Manufacturing, Tolerances and Quality Control — p. 241–262
13. Testing, Validation and Reference Tables — p. 263–280
