Floor Plans & House Designs-109

₹15,000.00

This design is open to customization!

Share your envisioned modifications with us, allowing us to generate a design service estimate for you. Simply press the button to send your pricing request. Please mention plan number.

MODIFY THIS PLAN

PLAN NUMBER:- 109

PLAN DESCRIPTION

Basic Features

Ground Floor

LIVING ROOM – 1
KITCHEN – 1
DINING ROOM – 1
MASTER BED ROOMS – 2
BED ROOM – 2
BATH ROOM – 3
STORAGE ROOM – 1
FRONT PORTICO – 1
CAR GARAGE – 1

Dimensions

Length :44′-5″
Width  : 58′-4″

Height : 15′

Area

Total 2816 Sq/Ft

Ground Floor 2816 sq/ft

WHAT’S INCLUDED IN THIS PLAN SET

  • Cover Sheet – May include index, front view of home, definitions, etc.
  • Dimensioned Floor Plan –
  • Exterior Views – Two exterior views of the residence with other miscellaneous details.
  • Roof Plan – Birds eye view showing all ridges, valleys and other necessary information
ADDITIONAL WORK PRICING
Plan Options

Foundation Plan

$80

Usually comprises a foundation plan complete with dimensions and specific footing information.



Electrical Plan

$80

Shows all essential electrical components, including lighting fixtures, outlets, and other required items, which may also be indicated on the Dimensioned Floor Plan

Wall Section

$80

Elaboration on wall materials and their construction.



Building Section

$80

Cross-section of the residence providing vital framing details and miscellaneous data.

Audio Video Design

$80

Get an overlay sheet indicating recommended positions for audio and video component

Material List

$80

Access a construction materials spreadsheet required for building the foundation of your new home. Please be aware that the materials list does not account for additional options like alternative foundations and framing.
