Description
Flange Pressure-Temperature Rating calculation spreadsheet to ASME B16.5
This asme b16.5 flange rating calculation workbook by 3D-LABS covers class rating lookup, bolt loads and gasket seating. You enter 17 design inputs and the sheet returns 12 key results with pass/fail checks, every formula visible and traceable to ASME B16.5. It is a ready-to-use Excel file for piping engineers, checkers and students who need a clear, auditable calculation rather than a black-box program.
Calculation steps
- Rated Pressure & Bolt Load Check
- Asme B16.5 Table 2 Rating With Temperature Derating, App. 2 Bolt Load
- Rated Pressure At Temperature
- Gasket Geometry
- Bolt Loads (App. 2)
- Bolt Capacity Check
Results you get
- Rating at 38 °C (MPa)
- Rated pressure at Td (MPa)
- Pressure utilisation
- Minimum class
- Gasket reaction dia G (mm)
- Operating load Wm1 (kN)
- Seating load Wm2 (kN)
- Governing load Wm (kN)
- Available bolt load (kN)
- Bolt torque (N·m)
- Rating check
- Bolt check
Codes and references
- ASME B16.5 — Pipe Flanges and Flanged Fittings NPS 1/2 through NPS 24 (2020)
- ASME B16.47 — Large Diameter Steel Flanges NPS 26 through NPS 60 (2020)
- ASME VIII Div. 1 App. 2 — Rules for Bolted Flange Connections with Gaskets (2023)
- ASME B16.20 — Metallic Gaskets for Pipe Flanges — spiral wound (2023)
- ASME B16.5 Table 1A — List of material specifications by group (2020)
What’s included
- Editable Excel workbook (.xlsx) — Flange-Pressure-Temperature-Rating-ASME-B16-5.xlsx
- Cover sheet with document number, revision and 3D-LABS title block
- Calculation sheet: colour-coded inputs (blue), formulas (black) and key results (yellow)
- Reference sheet listing the governing standards and editions
- Worked example pre-filled with realistic values
- One-click print to PDF for submission and checking
Frequently asked questions
Can I edit the formulas?
Yes. All cells are unlocked, so you can adapt the flange pressure-temperature rating calculation to your own project standards.
Which software do I need?
Microsoft Excel 2016 or later, or any compatible spreadsheet (LibreOffice, Google Sheets).
How do I receive the file?
The download link appears immediately after payment and is also emailed to you.
Is it a substitute for engineering review?
No. The sheet is a design aid — results must be verified by a qualified engineer before use.
What Flange Pressure-Temperature Rating (ASME B16.5) — Excel Calculator calculates
Flange Pressure-Temperature Rating (ASME B16.5) — Excel Calculator is an Excel-native engineering calculation tool built by 3D-LABS for engineers, designers, and technical consultants across disciplines. It is used for performing repeatable, verifiable engineering calculations that would otherwise require manual longhand work. Every input is labelled and every output is traceable — the sheet is designed to be checkable, not a black box.
Codes and standards followed
Flange Pressure-Temperature Rating (ASME B16.5) — Excel Calculator follows ASME B16.5. Each formula in the spreadsheet is cross-referenced to the specific code clause it implements — you can trace any calculation back to the underlying standard, which is essential for design review and regulatory sign-off.
If your project requires a different code base (e.g. converting an IS-code sheet to an ASME basis), we can produce a code-variant edition on request. Contact info@3d-labs.com for a variant quote.
What is included in your download
- The Excel calculation file (.xlsx) — fully unlocked formulas, cell-level comments, and a clear input/output layout.
- A sample worked example — realistic inputs plus expected outputs so you can validate the spreadsheet against a known case.
- User notes (PDF) — assumptions, code clauses referenced, and edge-case guidance.
- Revision history — every update to the spreadsheet is logged so you know what changed and when.
- Email support — reply within 24 hours (Monday to Saturday, IST) for questions about the spreadsheet or its use.
